SICK DLS40E-S3AV00360 Sensor
SICK DLS40E-S3AV00360 incremental encoder, part 1109594. Solid shaft, 360 ppr, six-channel TTL/RS-422 signals for cost-effective feedback.
Overview
The SICK DLS40E-S3AV00360 (part number 1109594) is an economical incremental rotary encoder of the DLS40 family with a solid shaft. It outputs six-channel signals in TTL/RS-422 level with 360 pulses per revolution per the order code, providing cost-effective feedback for standard drive and measurement tasks.
How It Works
Optical scanning produces incremental pulse trains including inverted channels and index, transmitted differentially via RS-422 for noise immunity. The controller counts pulses to derive speed and relative position, with the index channel supporting reference marking.
Key Features
- Six-channel incremental signals in TTL/RS-422 level
- 360 pulses per revolution (order code)
- Part number 1109594
- Solid shaft for coupling mounting
- Economic family for standard feedback tasks
- Differential transmission for noise-resistant wiring
Typical Applications
- Speed feedback on standard drives
- Length measurement on conveyors and feeders
- Position feedback with index referencing
- Feedback on packaging machinery
- Retrofit feedback on legacy equipment
Specifications
Attribute | Value |
|---|---|
Model | SICK DLS40E-S3AV00360 |
Part number | 1109594 |
Encoder type | Incremental rotary encoder, solid shaft |
Pulses per revolution | 360 (order code) |
Signal level | TTL/RS-422, 6-channel |
Installation and Setup Notes
Couple the encoder with a flexible coupling and align within the coupling's compensation limits. Use twisted-pair shielded cable for the differential signals and ground the shield at the controller. Verify all six channels are received correctly before releasing the machine.
Frequently Asked Questions
Why six channels?
A, B and index signals each with inverted counterparts enable differential RS-422 transmission with high noise immunity.
What does S3AV00360 define?
Interface, shaft and the 360 pulses per revolution of this DLS40E variant.
Can the index channel be used for homing?
Yes, the index pulse supports repeatable referencing within a revolution.
