SICK TIM781S-2174104 Sensor
SICK TIM781S-2174104 2D LiDAR sensor, part 1096363. Long-range scanning with configurable fields for large machine perimeters.
Overview
The SICK TIM781S-2174104 (part number 1096363) is a 2D LiDAR sensor of the TiM781S family. With a long scanning range and rugged housing, it monitors machine surroundings, detects vehicles and objects, and supplies field-based switching results for industrial mobile and stationary applications.
How It Works
The sensor rotates its laser beam across the scanning plane and evaluates the time of flight of each pulse. The resulting distance profile is processed into object detection within configurable fields, reported through the sensor interfaces with fast, deterministic behavior.
Key Features
- Long-range 2D LiDAR object detection
- Part number 1096363
- Configurable detection fields and zones
- Rugged housing for industrial environments
- Deterministic scan behavior for dynamic applications
- Flexible interface integration
Typical Applications
- Monitoring of large machine perimeters
- Object detection on heavy automated transport vehicles
- Area supervision at transfer and storage interfaces
- Collision-adjacent detection on mobile equipment
- Corridor monitoring on internal transport routes
Specifications
Attribute | Value |
|---|---|
Model | SICK TIM781S-2174104 |
Part number | 1096363 |
Detection principle | 2D LiDAR scanning |
Family | TiM781S LiDAR sensors |
Installation and Setup Notes
Choose the mounting height so the scan plane detects the relevant objects, and configure the fields to the application layout. Verify detection over the full speed and distance range of the process. Keep the window clean and inspect the mounting for loosening during maintenance intervals.
Frequently Asked Questions
What does the S in TiM781S indicate?
It identifies the synchronization-capable variant of the TiM781 family for multi-sensor installations.
Can it monitor several independent fields?
Yes, the family provides multiple configurable fields with separate outputs.
How does it differ from the TiM320?
The TiM781S covers longer distances and larger monitoring areas within the same compact housing concept.
