SICK C4C-EC01510A10000 Sensor
SICK C4C-EC01510A10000 safety light curtain receiver, part 1112993. C4-RD Type 4 unit, 150 mm field height, 10 mm resolution.
Overview
The SICK C4C-EC01510A10000 (part number 1112993) is a receiver unit (E code) of the C4-RD safety light curtain family, an economical solution for hazardous point protection. With a protective field height of 150 mm and a resolution of 10 mm, it helps safeguard fingers and hands at access points to machines and automated cells.
How It Works
The sender emits a grid of synchronized infrared pulses across the protected field, and the receiver evaluates which beams arrive. When an object enters the protective field and blocks a beam, the output circuit opens and the machine control brings the hazardous movement to a safe state. The system is evaluated for the family's Type 4 safety level per the applicable standards.
Key Features
- C4-RD family safety light curtain, 150 mm protective field height, 10 mm resolution
- Economical solution for hazardous point protection
- No blind zones thanks to sync technology
- Robust aluminum extruded profile housing
- Slim mounting brackets for machine integration
- Part number 1112993
Typical Applications
- Hazardous point protection on presses and forming machines
- Access protection on packaging machinery
- Hand protection at robot workstations
- Point-of-operation guarding on assembly equipment
- Entry monitoring on compact machine openings
Specifications
Attribute | Value |
|---|---|
Model | SICK C4C-EC01510A10000 |
Part number | part number 1112993 |
Device type | Safety light curtain, C4-RD family, receiver unit (E code) |
Protective field height | 150 mm |
Resolution | 10 mm |
Installation and Setup Notes
Mount sender and receiver opposite each other using the slim brackets, align them so all beams are received, and verify alignment status before enabling the machine. Wire the output circuit dual-channel into the safety controller as required for the applied safety level. Check protective field height and resolution against the risk assessment of the machine.
Frequently Asked Questions
Do sender and receiver need separate order codes?
Yes, the C4-RD system consists of a sender (S code) and a receiver (E code) with matching field height and resolution.
Is a separate alignment routine needed?
The units provide alignment support through status indicators; after bracket mounting, confirm the alignment status shows all beams received.
Which safety level does the family support?
The C4-RD family is designed for Type 4 applications per its specification, suitable for finger and hand protection.
Related Safety Products
For the matching counterpart or other field heights, see the C4-RD family listings such as the SICK C4C-EC07530A10000 and SICK C4C-SC07530A10000.
