SICK OD2000-0301T15 Sensor
SICK OD2000-0301T15 laser triangulation displacement sensor, part 6074380. High-resolution displacement measurement for quality control.
Overview
The SICK OD2000-0301T15 (part number 6074380) is a laser triangulation displacement sensor of the OD2000 family. It measures distances and displacements with high resolution on nearly any surface, providing precise position values for quality control and machine monitoring tasks.
How It Works
Laser triangulation projects a light spot onto the target at a defined angle. The reflected spot position on the internal receiver changes with the target distance, and the electronics convert this shift into a high-resolution displacement value. The method delivers micrometer-class resolution on suitable surfaces.
Key Features
- High-resolution laser triangulation displacement measurement
- Precise values on nearly any surface color and material
- Part number 6074380
- Compact sensor head for machine integration
- Fast sampling for dynamic displacement processes
- Robust controller housing within the family
Typical Applications
- Thickness and height measurement on production lines
- Runout and eccentricity monitoring on rotating parts
- Position verification of precision machine axes
- Deformation and deflection monitoring under load
- Quality checks of surface profiles
Specifications
Attribute | Value |
|---|---|
Model | SICK OD2000-0301T15 |
Part number | 6074380 |
Detection principle | Laser triangulation displacement measurement |
Family | OD2000 displacement sensors |
Installation and Setup Notes
Observe the family's standoff distance so the spot falls within the measuring range, and mount both sensor head and target reference rigidly. For shiny surfaces, angle the sensor slightly to avoid direct mirror reflection into the receiver. Calibrate zero and span against gauge blocks for metrology-grade tasks.
Frequently Asked Questions
How precise is triangulation compared with time of flight?
Triangulation provides far higher resolution at short ranges, which suits displacement and profile tasks.
Can it measure hot surfaces?
Yes, with attention to family temperature limits and emitted glow light; test with the real process.
What does the T15 order code include?
It identifies the optics and connection configuration of this OD2000 variant.
